Max. Power | 200A (2s) |
Sustained current | 140 A |
Telemetry | Duplex EX, Hott, MSB, S.Bus2, SRXL2, P2Bus |
Operating Voltage | 10-51 |
Operational temperature (°C) | -10 |
Batteries NiXX | -10÷110 |
Batteries LiXX | 4-12 |
Max. Current BEC (A) | 30A (2s) |
Voltage BEC (V) | 5.5 – 8.4 |
High-power controller of BLDC motors offers continuous current up to 140A at a voltage of up to 51V (12S LiPo). It offers a high-quality stabilized voltage output (BEC) with a continuous current of up to 15A and the possibility of connecting an external shutdown switch as well as cooling fan. The controller provides complete telemetry including voltage and current of the BEC circuit.
Additional functions
Option to activate the synchronous rectification (Active Freewheeling) for more accurate motor response and less heating of the controller during aerobatics.
Optional use of external on-off switch / push button / Hall-sensor / RC switch / Touch Switch.
Flawless operation with high power multi-pole motors and the vast majority of all other motor types.
Optional connection of backup battery without additional adapters.
Propeller positioning using a Hall sensor.
Optional external motor identification chip combined with a temperature sensor.
